Round air exhauster type C WDO-C

Air intake / exhauster and ventilation caps > Round air exhauster type C WDO-C
Air intake / exhauster and ventilation caps > Round air exhauster type C WDO-C
  • Air intake / exhauster and ventilation caps > Round air exhauster type C WDO-C
  • Air intake / exhauster and ventilation caps > Round air exhauster type C WDO-C
« previous product back to category next product »
« previous back next »

Material:

  • galvanized steel.

Product characteristics:

  • used as a terminal part of ventilation system;
  • special design protects the system against weather conditions;
  • as a standard manufactured on pipe connection;
  • as an option - can be produced with VKPK flange or male coupling end.
ød [mm] H [mm] øD [mm] Packaging [pcs | type]
100 245 200 5 P12
125 265 250 9 P4
150 330 300
160 340 320 4 P4
200 455 400 4 P2
250 545 500 2 P2
315 675 630 2 P1
355 745 710
400 835 800
500 1025 1000
630 1290 1260
Tolerance of linear dimensions: ±2 mm.
